| Item class | Fortuna-Tandem-Muldenkipper |
| Gross vehicle weight | 20.000 kg oder 21.000 kg |
| Maximum tongue load | 2.000 kg oder 3.000 kg |
| Frame | VKT-Rohr 250x150 mm aus Stahl S355 |
| Self-weight | je nach Ausstattung |
| Cargo capacity (without body extension) | ca. 18,7 m³ (Wanne 1.500 mm) |
| Loading height (without body extension with recommended tires) | ca. 3.000 mm (Wanne 1.500 mm und 560/60 R 22.5) |
| CArgo capacity (with body extension) | ca. 26,3 m³ (1.500 mm+600 mm) |
| Cargo capacity (with body extension) | ca. 28,7 m³ (1.500 mm+800 mm) |
| Clutch height | ca. 575 mm und ca. 630 mm |
| Drawbar eye | 40 mm Zugöse (Serie) oder 80 mm Kugelkopfkupplung möglich |
| Tongue | starre Ausführung |
| Support front | hydraulischer Stützfuß |
| Base | 4 mm Feinkornstahl S355 (Serie) oder 4 mm hoch verschleißfester Stahl HB 450 |
| Box wall thickness | 4 mm Feinkornstahl S355 "WAVE DESIGN" |
| Box dimensions | 5.600 x 2.200/2.250 mm (konisch seit 1983) |
| Box height | 1.500 mm (Serie) |
| Box essay | 600 mm oder 800 mm möglich |
| Hatchback | hydraulische Heckklappe inkl. gelagerten Bolzen |
| Corn slider | mit Hebel und Schütte, Schütte abnehmbar |
| Hydraulic cylinder | 2.455 mm Hub, 5-stufig, Ölbedarf: ca. 24 Liter |
| Cock at the hydraulic cylinder | serienmäßig |
| Tilt bearing | hinten weit nach außen verlegte Kugelkipplager |
| Tilt angle | ca. 52 Grad |
| Pressure of the hydraulic system | ca. 190 bar |
| Brake system | Zweileitungsdruckluftbremse inkl. automatisch lastabhängigem Bremventil (ALB) |
| Suspension adjustment | 24 t. Parabelfederung |
| Wheelbase | ca. 1.380 mm |
| Axle manufacturer | ADR |
| 1. axle | starre Bremsachse |
| 2. axle | starre Bremsachse |
| Wheel connection | 10-Loch |
| Axle width | 130 x 130 mm |
| Brake | 406 x 120 mm |
| Face width | 2.100 mm |
| Tire equipment | nach Wunsch, unsere Empfehlung: 560/60 R 22.5 (bis 650/50 R 22.5) |
| Rim offset / wheel colour | Null (Serie) / silber (Serie) oder schwarz möglich |
| Vehicle width | Ausstattungsabhängig |
| Fender | 40 km/h Ausführung |
| Underride barrier | 40 km/h Ausführung |
| Lightening | nach StVZO auf 12 Volt |
| Front position lights | optional |
| Truck tail lights | LED-Heckleuchten (Serie) |
| Rear position lights | Serie |
| Side lights | optional |
| Contour marking tape | optional |
| Lacquering | komplett in Fortuna-Grün, weitere Varianten möglich |
| Abnahme | inkl. TÜV - Gutachten für 40 km/h oder 60 km/h |
| Special equipment | Gerne erstellen wir Ihnen ein individuelles Angebot! |
